11

Starting Operation

6-1 Retrofitting for mulching mower

WARNING: Only with a stopped engine and

standstill cutter.

1. Raise the rear cover and remove the grass catcher.

(Fig. 16)

2. Push the mulching wedge into the deck. Lock the

mulching wedge with the button into the opening on

the deck. (Fig. 17)

3. Lower the rear cover again.

6-2 Resetting for side-discharge mowing

Only when engine and cutting are at standstill!

1. Raise the rear cover and remove the grass catcher.

(Fig. 16)

2. Push the mulching wedge into the deck. Lock the

mulching wedge with the button into the opening on

the deck. (Fig. 17)

3. Lift sideward flap for side discharge. (Fig. 18)

4. Mount the discharge channel for side discharge on the

support pin of the sideward flap. (Fig. 18)

5. Lower the sideward flap on the discharge channel.

(Fig. 19)

6-3 Mowing with the grass catcher

WARNING: Only with a stopped engine and

standstill cutter.

For mowing with the grass catcher, remove the mulching

wedge and discharge channel for side discharge and

mount the grass catcher.

1. Removing the mulching wedge:

- Lift rear cover and remove the mulching wedge.

2. Removing the discharge channel for side discharge:

- Lift sideward flap and remove side discharge channel.

- The sideward flap automatically closes the discharge

opening on the housing by mean of spring force.

- Regularly clean the sideward flap and discharge

opening form grass rest and stuck dirt.

3. Mount the grass catcher:

- Raise the rear cover and hitch the grass catcher on

rear of mower.

7. OPERATING INSTRUCTIONS

7-1 BEFORE STARTING

Service the engine with gasoline and oil as instructed in

the separate engine manual packed in your mower. Read

instructions carefully.

WARNING: Petrol is highly flammable.

Store fuel in containers specifically designed for this

purpose.

Refuel outdoors only, before starting the engine and do

not smoke while refueling or handling fuel.

Never remove the cap of the fuel tank or add petrol while

the engine is running or when the engine is hot.

If petrol is spilled, do not attempt to start the engine but

move the machine away from the area of spillage and

avoid creating any source of ignition until petrol vapors

have dissipated.

Replace all fuel tanks and container caps securely.

Before tipping the lawn mower to maintain the blade or

drain oil, remove fuel from tank.

WARNING: Never fill fuel tank indoors, with

engine running or until the engine has been allowed to

cool for at least 15 minutes after running.

7-2 TO START ENGINE AND ENGAGE

BLADE

1. The unit is equipped with a rubber boot over the end of

the spark plug, make certain the metal loop on the end

of the spark plug wire (inside the rubber boot) is

fastened securely over the metal tip on the spark plug.

2. When starting cool or warm engine, turn throttle choke

lever at anywhere between “ ” position to “ ”

position. When operating, turn throttle choke lever to

“ ” position. (Fig. 20)

3. Standing behind the unit, grasp the stop control

handle and hold it against the upper handle as shown

in Fig. 21.

4. Grasp the starter handle as shown Fig. 21 and pull it

up rapidly. Return it slowly to the rope guide bolt after

engine starts. Release the stop control handle to stop

the engine and blade.

Start the engine carefully according to

instructions and with feet well away from the

blade.

Do not tilt the lawn mower when starting the

engine. Start the mower on a level surface, free

of high grass or obstacles.

Keep hands and feet away from the rotating

parts. Do not start the engine when standing in

front of the discharge opening.

7-3 OPERATION PROCEDURES

During operation, tightly hold the stop control handle with

both hands.

Note: During operation, when the stop control

handle is released, the engine will stop and thus stopping

the lawn mower from operating.

WARNING! In order to avoid any unintentional

start-ups of the lawn mower, it comes equipped with an

engine brake which must be pulled back before the

engine can be started. When the engine control lever is

released it must return to its initial position, at which point

the engine automatically switches off.
