EN

Quick Guide

3

INTERNAL LIGHTS  When the feature is active the LEDs in the tub are

automatically switched on/o as soon as the user open/close the door

respectively.

If the door remains opened for more than 10 min, the LEDs in the

tub switch o (to turn them on again, the door has to be closed and opened

again).

This feature is active by default, but it is possible to deactivate it in

the “SETTINGS MENU”.

SENSING - When the sensor is detecting the soil level an

animation appears in the display (around 20 min.) and the cycle

duration is updated. SENSING is for the level of soiling on the

dishes and is present for all cycles (excepting Eco) adjusting the program

accordingly.

CARE AND MAINTENANCE

More information in the Daily Reference Guide on website.

LOADING THE RACKS

CAPACITY: 15 standard place-settings

CYCLE COUNTER - This feature shows the number of cycles the

dishwasher has performed.

For the number of cycles from 0-999, a xed number will be displayed.

Example for 25 cycles.

When the cycle number is higher than 1000, the number will scroll in

the display. The “_” represents the “

.

”, as for instance: 1.000 = 1_000,

13.947= 13_947 (the number will scroll for 3 times).

Example for

13.947 cycles:

After the cycle visualization, the display will return to visualize

„ ”

.

NOTE: The dishwasher may have already performed about 30 cycles.

This is due to the extended quality process carried out during

production. It guarantees higher product quality.

TOP RACK

The top rack pro-

vides a targeted

cleaning Wash Zone

for bowls, mugs,

even big plates and

cutlery that you’d

normally load in the

lower racks, making

extra space for the rest of the day’s dishes.

A separate arrangement of the cutlery makes

collection easier after washing and improves

washing and drying performance.

Knives and other utensils with sharp edges

must be positioned with the blades facing

downwards.

UPPER RACK

Load delicate and light dishes: glasses, cups,

saucers, low salad bowls.

The upper rack has tip-up supports which can

be used in a vertical position when arranging

tea/ dessert saucers or in a lower position to

load bowls and food containers.

(loading example for the upper rack)

ADJUSTING THE HEIGHT OF THE UPPER RACK

The height of the upper rack can be adjusted: ahigh po-

sition to place bulky crockery in the lower basket and

alow position to make the most of the tip-up supports

by creating more space upwards and avoiding collision

with the items loaded into the lower rack.

We strongly recommend that you do not adjust the

height of the rack when it is loaded. NEVER raise or

lower the basket on one side only.

FOLDABLE FLAPS WITH ADJUSTABLE POSITION

The side foldable aps can be folded or unfolded to opti-

mize the arrangement of crockery inside the rack. Wine

glasses can be placed safely in the foldable aps by insert-

ing the stem of each glass into the corresponding slots.

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc. Large

plates and lids should ideally be placed at the

sides to avoid interferences with the spray arm.

The lower rack has tip-up supports which can

be used in a vertical position when arranging

plates or in ahorizontal position (lower) to load

pans and salad bowls easily.

(loading example for the lower rack)

POWER CLEAN®

Power Clean® uses the special water jets in the

rear of cavity to wash more intensively the high

dirty items. The lower rack has a Space Zone,

aspecial pull-out support in the rear of the rack that can be used to support

frying pans or baking pans in upright position, thus taking up less space.

Placing the pots/casseroles faced to the Power Clean® component please

activate the POWER CLEAN® on the panel.

CUTLERY BASKET

It is tted with top grids for improved cutlery arrangement.

It must only be positioned at the front of the lower rack.

Knives and other utensils with sharp edges must be

placed in the cutlery basket with the points facing

downwards or they must be positioned horizontally

in the tip-up compartments on the upper rack.

CLEANING THE FILTER ASSEMBLY

A

A

B

C

1 2 3 4

The dishwasher must not be used without l-

ters or if the lter is loose.

It is important when reinstalling the lter that

the two triangles shown on the zoom meet (Fig 1).

In case you nd foreign objects (such as broken

glass, porcelain, bones, fruit seeds etc.) please re-

move them carefully.

Inspect the trap and remove any food residues.

NEVER REMOVE the wash-cycle pump protec-

tion (shown by an arrow) (Fig 4).
