2

KEYLOCK - A long press (for 3 seconds) of TURBO button, will activate

the KEYLOCK function. To deactivate the KEYLOCK, long press again.

DELAY -The start of the program may be delayed for a period of time

between 0:30 and 24 hours

The DELAY function cannot be set once a wash cycle has been started.

POWER CLEAN - Thanks to the additional power jets this option provides

a more intensive and powerful wash in the lower rack, in the specic area.

This option is recommended for washing pots and casseroles.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

MULTIZONE - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent. By default the

appliance washes dishes in all racks.

Please scan the QR code on your product in order to have more detailed information.

NaturalDry It is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying

performance every day. The door opens at a temperature that is safe to

your kitchen furniture.

More information in the Daily Reference Guide on the website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1

A

2

A

B

3

C

4

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product’s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label.

The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

:

CUTLERY RACK

(loading example for the

cutlery rack)

The third rack was desi-

gned to house the cutlery.

UPPER RACK

(loading example for the

upper rack)

Load delicate and light

dishes: glasses, cups, sa-

ucers, low salad bowls.

Foldable

aps with

adjustable

position

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc.

Large plates and lids should ideally be placed at

the sides to avoid interferences with the spray

arm.

The lower rack has tip-up supports which can

be used in a vertical position when arranging

plates or in a horizontal position (lower) to load

pans and salad bowls easily.

(loading example for the lower rack)

POWER CLEAN

Power Clean uses the special water jets in the rear of cavity to wash more in-

tensively the high dirty items. The lower rack has a Space Zone, a special pull-

-out support in the rear of the rack that can be used to support frying pans or

baking pans in upright position, thus taking up less space.

Placing the pots/casseroles faced to the Power Clean®

component please activate the POWER CLEAN on the

panel.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

400011639701C

08/2022 dk - Xerox Fabriano

TROUBLESHOOTING

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows:

and F6, both On/

O and START/Pause

LEDs are blinking

rapidly.

No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher and

reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it.

After having carried out the verication and cleaning, turn o and turn on the dishwasher

and restart a new program.

Dishwasher nishes

the cycle prematurely.

Display shows: F15

and both On/O and

START/Pause LEDs are

blinking rapidly.

Drain hose positioned too low or siphoning into

home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check for siphoning

into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

Please scan the QR code on your product in order to have more detailed information.
