Vadovas JBL Charge 5 Wi-Fi SE Garsiakalbis

Vadovas

WARNING!

WITH USB-C CHARGING PROTECTION, A REMINDER SOUND WILL ALERT YOU TO UNPLUG IF THE CONNECTOR DETECTS WATER, SALT, OR ANY OTHER CHEMICALS.

DO NOT CHARGE YOUR SPEAKER UNTIL IT IS COMPLETELY DRY AND CLEAN.

1 2

*SMART SPEAKER SOLD SEPARATELY

*

COMPLETE SETUP IN THE GOOGLE HOME OR AMAZON ALEXA APP.

VOICE ASSISTANT COMPATIBILITY

JBL ONE

CONNECT YOUR ANDROID™ OR IOS DEVICE TO THE WI-FI NETWORK AND FOLLOW

APP INSTRUCTIONS TO COMPLETE SPEAKER SETUP*.

*THE AVAILABILITY OF FEATURES WILL VARY BETWEEN COUNTRIES AND NOT ALL FEATURES MAY BE

AVAILABLE IN YOUR COUNTRY.

Wi-Fi

APP

1 2

MULTI-SPEAKER

CONNECTION

ON

TECH SPEC

CHARGE5

Wi-

Fi SE

QUICK START

GUIDE

GUIDE DE

DÉMARRAGE

RAPIDE

WHAT’S

IN THE

BOX

POWER ON

STREAM MUSIC THROUGH JBL ONE APP OR SUPPORTED MUSIC SERVICES.

MUSIC STREAMING

ON

Settings Bluetooth

Bluetooth

DEVICES

JBL Charge 5 Wi-Fi SE

Now Discoverable

Connected

×1

1 2

BLUETOOTH PAIRING

MOMENT

PRESS TO PLAY THE SET PLAYLIST AND SPEAKERS SETTING PRESET IN THE JBL ONE APP.

×2

×1

PLAY

100%

50%

20%

( *NOT INCLUDED )

( *NOT INCLUDED )

CHARGING

WATERPROOF

DUSTPROOF

IP68

1.5 M 30 MINS

Transducer: 53 x 93mm woofer, 20mm tweeter

Rated output power: 30W RMS for woofer, 10W RMS for tweeter

Frequency response: 60Hz - 20kHz

Signal-to-noise ratio: > 80dB

Battery type: Li-ion polymer 52Wh

(equivalent to 3.69V/14100mAh)

Battery charge time: 6 hours (5V/3A)

Music play time: up to 20 hours (dependent on volume level

and audio content)

USB ports: USB Type A x1, USB Type C x1

USB charge out:

5V/2A (maximum)

Bluetooth version: 5.3

Bluetooth profile: AVRCP 1.5 and A2DP1.3

Bluetooth transmitter frequency range: 2.4GHz-2.4835GHz

Bluetooth transmitter power: <13dBm (EIRP)

Bluetooth transmitter modulation: GFSK, π/4-DQPSK, 8DPSK

5G Wi-Fi transmitter frequency range: 5.15-5.35GHz, 5.470-5.725GHz,

5.725-5.825GHz

5G Wi-Fi transmitter power: <23dBm

5G Wi-Fi modulation: OFDM (BPSK, QPSK, 16QAM, 64QAM,

256QAM, 1024QAM)

5G Wi-Fi network compatibility: 802.11a/n/ac/ax

2.4G Wi-Fi transmitter frequency range: 2.4GHz-2.4835GHz

2.4G Wi-Fi transmitter power: <20dBm

2.4G Wi-Fi modulation: DSSS (DBPSK, DQPSK, CCK),

OFDM (BPSK, QPSK, 16QAM, 64QAM,

256QAM, 1024QAM)

2.4G Wi-Fi network compatibility: 802.11 b/g/n/ax

Product dimensions (W x H x D): 223 x 97 x 94mm/8.8 x 3.8 x 3.7"

Net weight: 1.0kg/2.2lbs

Packaging dimensions (W x H x D): 257 x 131 x 120mm/10.1 x 5.2 x 4.7"

Gross weight: 1.7kg/3.7lbs

Maximum operation temperature: 45°C

* Factory reset: To restore the factory settings, hold and for more than 10 seconds.

CONTENU

DE LA

BOÎTE

MISE EN MARCHE

PA_JBL_Charge 5 Wi-Fi SE_QSG_US_PV_V2.indd 1PA_JBL_Charge 5 Wi-Fi SE_QSG_US_PV_V2.indd 1 2025/1/10 16:14:252025/1/10 16:14:25
