CLEANING & MAINTENANCE
• Always unplug the appliance from power
before cleaning.
• Never immerse the appliance or power cord in
water. Do not let the electrical parts come into
contact with moisture.
• Clean the housing of the unit with a damp
cloth and then wipe it dry.
• Deposits and other residues on the sole plate
can be removed with a little vinegar.
• Do not use any abrasives to clean the sole
plate!
• Always store the iron in the locked position.
DESCALE (Fig. B)
If the descaling indicator lights up, the steam
generator must be cleaned as mineral deposits
have accumulated. When the system ensures that
the mineral deposits have been removed, the
indicator goes out.
Note: The descaling function can only be
performed when the descaling indicator is
constantly lit.
To remove the mineral deposits, follow the steps
below:
1. Caution: Make sure that the appliance is
disconnected from the mains and has cooled
down completely before proceeding to avoid
the risk of scalding.
2. Remove the water tank from the base unit.
3. Turn the base unit upside down and place it on
a level surface to gain access to the sealing cap
of the steam generator on the bottom of the
unit.
4. Cover the sealing cap with a towel and turn it
counterclockwise to open it.
5. Take the silicone drain hose that is attached at
the bottom of the base and connect it to the
drain port.
6. Place the base unit on a table and put the
silicon hose into a container.
7. Fill the water tank with clean water and insert
it.
8. Connect the power cord to the mains and
switch on the appliance.
9. Press and hold the descale button and the
steam trigger at the same time for 2 seconds
until you hear a beep and the descaling
indicator starts ashing.
10. Now the appliance starts to ush the steam
generator. Water, steam and scale ows out of
the steam generator. About 3 minutes later,
the descaling indicator stops ashing and the
appliance switches o automatically.
11. After that, disconnect the appliance from the
power outlet, remove the water tank and the
drain hose and tighten the sealing cap on the
bottom again.
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working electrical
equipment to an appropriate waste disposal
center.
FILLING WITH WATER
The steam ironing station may be used with tap
water, but if you live in an area with hard water,
you should use distilled or demineralized water.
Do not use chemically descaled water or other
liquids to ll the tank and do not add anything to
the water as this may damage the steam ironing
station.
• Make sure that the appliance is disconnected
from the mains and has cooled down.
• Remove the water tank and poor water into
the water lling hole - Do not overll.
• Now put the lled tank back in place. Make
sure it is properly snaped in.
SWITCH ON
• Place the iron on the base unit and connect the
power cord to the mains.
• Press the power button to switch on the steam
ironing station.
• Set the temperature control to the correct
temperature for the fabric.
• During heating, the temperature indicator of
the iron is on and the steam rate indicator is
ashing.
• When the steam function is ready for use, the
steam rate indicator lights up constantly.
• When the iron reaches the set temperature,
the temperature indicator of the iron goes o.
It will then cycle on and o as the thermostat
operates to maintain the temperature.
TEMPERATURE SETTINGS GUIDE
Fabric label Setting
Lower temperature
(synthetics, nylon, acrylics,
polyester)
Medium temperature
(wool, polyester mixtures)
High temperature
(cotton, linen)
/ max
Do not iron
Note: If the instructions on the fabric label dier
from this guide, follow the instructions on the
label.
STEAM RATE CONTROL
The steam rate can be selected by pressing the
steam rate button. The options are low, medium
and high. The indicator for the selected steam rate
ashes until preheating is complete. The steam
rate indicator lights up constantly, when the
steam function is ready for use.
STEAM IRONING
If you intend to use steam, it should only be used
at higher ironing temperatures, otherwise the iron
may drip.
• Make sure the tank is lled with water.
• Set the temperature control between
and
/max. (The area is marked by the steam
icon “ ”)
• Select the desired steam rate.
• Wait until the steam rate indicator lights up
constantly.
• Press and hold the steam trigger to generate
steam during ironing.
• You can also double-tap the steam trigger to
activate continuous steam for 6 minutes or
until you press the steam trigger again.
• With this steam ironing station you can also
easily iron vertically. This is especially useful for
curtains, hanging garments, etc.
Note: As long as the steam function is active, the
device produces a pumping noise while water is
being pumped into the steam generator. This is
normal.
DRY IRONING
• Set the temperature control to a setting
appropriate for the garment.
• Wait until the temperature indicator of the iron
goes o, then start ironing.
AUTO OFF
The appliance switches o automatically if there is
no operation within 10 minutes. To switch it back
on, simply press the power button again.
AFTER USE
• Set the temperature control to minimum.
• Place the iron on the base unit and lock it.
• Press and hold the power button for 2 seconds
to turn o the appliance.
• Unplug the power cord from the power outlet.
• Let it cool down completely.
• We recommend emptying the water tank after
each use to avoid limescale deposits.
• Proceed with “CLEANING & MAINTENANCE”
